2 Core Foil-Shielded PA / Intercom Cable
KEY FEATURES
- Two stranded bare-copper conductors
- Overall aluminium/polyester foil screen and drain wire
- PVC, LSZH and PE Outdoor jacket options
- Exact searchable Series item codes
- 305 m controlled standard package
Description
TMT Global 2 Core Foil-Shielded PA / Intercom Cable Series
TMT Global 2 Core Foil-Shielded PA / Intercom Cable is a configurable bulk-cable family for public-address audio, intercom, paging and low-voltage control circuits where overall foil screening is required. The family page carries exact AWG and jacket item codes without creating duplicate WooCommerce pages.
KEY FEATURES
- Two stranded bare-copper conductors
- Overall aluminium/polyester foil screen and drain wire
- PVC, LSZH and PE Outdoor jacket options
- Exact searchable Series item codes
- 305 m controlled standard package
TYPICAL APPLICATIONS
- Public-address audio circuits
- Intercom and paging systems
- Sound-system control wiring
- Commercial building audio interfaces
- Indoor and outdoor system routes
Technical Specification
| PARAMETER | SPECIFICATION |
| Product type | PA / paging / intercom bulk cable |
| Geometry / configuration | 2 core |
| Conductor material | Bare copper |
| Conductor construction | Stranded copper conductors |
| Available conductor sizes | 14 AWG / 16 AWG / 18 AWG / 20 AWG / 22 AWG |
| Conductor identification | Colour-coded insulated conductors |
| Core / pair construction | 2 colour-coded insulated conductors |
| Screening | Overall foil screen |
| Drain wire | Drain wire included |
| Outer-jacket options | PVC / LSZH / PE Outdoor |
| Cable form | Round |
| Standard colours | Grey (PVC/LSZH) / Black (PE Outdoor) |
| Package length | 305 m standard package |
| Typical applications | Public-address, intercom, paging and low-voltage control circuits |
AWG / NOMINAL AREA / SERIES AVAILABILITY
| AWG | NOMINAL AREA | SERIES AVAILABILITY |
| 14 AWG | 2.08 mm² | PVC / LSZH / PE Outdoor • 305 m |
| 16 AWG | 1.31 mm² | PVC / LSZH / PE Outdoor • 305 m |
| 18 AWG | 0.823 mm² | PVC / LSZH / PE Outdoor • 305 m |
| 20 AWG | 0.519 mm² | PVC / LSZH / PE Outdoor • 305 m |
| 22 AWG | 0.326 mm² | PVC / LSZH / PE Outdoor • 305 m |
Additional information
| Brand | TMT Global |
|---|---|
| Jacket Type | LSZH, PE Outdoor, PVC |
| AWG | 14 awg, 16 awg, 18 awg, 20 awg, 22 awg |
| Colour | Black, Grey |
| Length | 305 m |
Ordering Information
| Item Name | Item Code / SKU | Series | AWG / mm² | Pack | QR Code |
|---|---|---|---|---|---|
| 2 Core Foil-Shielded PA / Intercom Cable | 02C-S-PA | 14 awg | 305 m |  | |
| 2 Core Foil-Shielded PA / Intercom Cable | 02C-S-PA | 16 awg | 305 m | | |
| 2 Core Foil-Shielded PA / Intercom Cable | 02C-S-PA | 18 awg | 305 m | | |
| 2 Core Foil-Shielded PA / Intercom Cable | 02C-S-PA | 20 awg | 305 m | | |
| 2 Core Foil-Shielded PA / Intercom Cable | 02C-S-PA | 305 m | |
