4 Core Foil-Shielded PA / Control Cable
KEY FEATURES
- Four stranded bare-copper conductors
- Overall aluminium/polyester foil screen
- Drain wire for screen termination
- PVC, LSZH and outdoor PE options
- Exact AWG and jacket ordering rows
Description
TMT Global 4 Core Foil-Shielded PA / Control Cable Series
TMT Global 4 Core Foil-Shielded PA / Control Cable is a versatile public-address and commercial-audio family for paired audio/control conductors, zone-control wiring and intercom circuits. The overall foil screen supports installations near lighting, power and building-service wiring.
KEY FEATURES
- Four stranded bare-copper conductors
- Overall aluminium/polyester foil screen
- Drain wire for screen termination
- PVC, LSZH and outdoor PE options
- Exact AWG and jacket ordering rows
TYPICAL APPLICATIONS
- PA zone-control wiring
- Intercom and paging systems
- Commercial-audio control circuits
- Sound-system interfaces
- Building communication systems
Technical Specification
| PARAMETER | SPECIFICATION |
| Product type | Screened PA / control bulk cable |
| Geometry / configuration | 4 core |
| Conductor material | Bare copper |
| Conductor construction | Stranded copper conductors |
| Available conductor sizes | 14 AWG / 16 AWG / 18 AWG / 20 AWG / 22 AWG |
| Conductor identification | Colour-coded insulated conductors |
| Core / pair construction | 4 colour-coded insulated conductors |
| Screening | Overall foil screen |
| Drain wire | Drain wire included |
| Outer-jacket options | PVC / LSZH / PE Outdoor |
| Cable form | Round |
| Standard colours | Grey (PVC/LSZH) / Black (PE Outdoor) |
| Package length | 305 m standard package |
| Typical applications | PA audio, zone control, intercom and auxiliary system circuits |
AWG / NOMINAL AREA / SERIES AVAILABILITY
| AWG | NOMINAL AREA | SERIES AVAILABILITY |
| 14 AWG | 2.08 mm² | PVC / LSZH / PE Outdoor • 305 m |
| 16 AWG | 1.31 mm² | PVC / LSZH / PE Outdoor • 305 m |
| 18 AWG | 0.823 mm² | PVC / LSZH / PE Outdoor • 305 m |
| 20 AWG | 0.519 mm² | PVC / LSZH / PE Outdoor • 305 m |
| 22 AWG | 0.326 mm² | PVC / LSZH / PE Outdoor • 305 m |
Additional information
| Colour | Black, Grey |
|---|---|
| Jacket Type | LSZH, PE Outdoor, PVC |
| Length | 305 m |
| Brand | TMT Global |
| AWG | 14 awg, 16 awg, 18 awg, 20 awg, 22 awg |
Ordering Information
| Item Name | Item Code / SKU | Series | AWG / mm² | Jacket | Colour | Pack | QR Code |
|---|---|---|---|---|---|---|---|
| 4 Core Foil-Shielded PA / Control Cable | 04C-S-PA | 14 awg | PVC | Grey | 305 m |  | |
| 4 Core Foil-Shielded PA / Control Cable | 04C-S-PA | 14 awg | LSZH | Grey | 305 m | | |
| 4 Core Foil-Shielded PA / Control Cable | 04C-S-PA | 14 awg | PE Outdoor | Black | 305 m | | |
| 4 Core Foil-Shielded PA / Control Cable | 04C-S-PA | 16 awg | PVC | Grey | 305 m | | |
| 4 Core Foil-Shielded PA / Control Cable | 04C-S-PA | 16 awg | LSZH | Grey | 305 m | | |
| 4 Core Foil-Shielded PA / Control Cable | 04C-S-PA | 16 awg | PE Outdoor | Black | 305 m | | |
| 4 Core Foil-Shielded PA / Control Cable | 04C-S-PA | 18 awg | PVC | Grey | 305 m | | |
| 4 Core Foil-Shielded PA / Control Cable | 04C-S-PA | 18 awg | LSZH | Grey | 305 m | | |
| 4 Core Foil-Shielded PA / Control Cable | 04C-S-PA | 18 awg | PE Outdoor | Black | 305 m | | |
| 4 Core Foil-Shielded PA / Control Cable | 04C-S-PA | 20 awg | PVC | Grey | 305 m | | |
| 4 Core Foil-Shielded PA / Control Cable | 04C-S-PA | 20 awg | LSZH | Grey | 305 m | | |
| 4 Core Foil-Shielded PA / Control Cable | 04C-S-PA | 20 awg | PE Outdoor | Black | 305 m | | |
| 4 Core Foil-Shielded PA / Control Cable | 04C-S-PA | 22 awg | PVC | Grey | 305 m | | |
| 4 Core Foil-Shielded PA / Control Cable | 04C-S-PA | 22 awg | LSZH | Grey | 305 m | | |
| 4 Core Foil-Shielded PA / Control Cable | 04C-S-PA | 22 awg | PE Outdoor | Black | 305 m | |
