4 Core Enhanced Fire-Resistant Voice Alarm Cable
KEY FEATURES
- 4 copper conductors with enhanced fire-resistant insulation system
- Overall foil screen and drain wire
- LSZH sheath for critical public buildings
- Red, orange and white project colours
- Enhanced fire-resistance target subject to evidence
Description
TMT Global 4 Core Enhanced Fire-Resistant Voice Alarm Cable Series
TMT Global 4 Core Enhanced Fire-Resistant Voice Alarm Cable is an enhanced circuit-integrity family for voice-alarm, emergency communication and evacuation systems that must continue operating under severe fire conditions. Enhanced or PH120 claims remain blocked until the exact factory construction is supported by accepted test evidence.
KEY FEATURES
- 4 copper conductors with enhanced fire-resistant insulation system
- Overall foil screen and drain wire
- LSZH sheath for critical public buildings
- Red, orange and white project colours
- Enhanced fire-resistance target subject to evidence
TYPICAL APPLICATIONS
- Multi-phase evacuation systems
- Enhanced voice-alarm circuits
- Emergency voice communication
- High-rise and critical buildings
- Fire-safety communication backbones
Technical Specification
| PARAMETER | SPECIFICATION |
| Product type | Fire-resistant screened voice-alarm / emergency communication cable |
| Geometry / configuration | 4 core |
| Conductor material | Bare copper |
| Conductor construction | Stranded copper conductors |
| Available conductor sizes | 14 AWG / 16 AWG / 18 AWG |
| Fire-resistance family | Enhanced fire-resistant construction family; exact tested classification supplied with approved product documentation |
| Core / pair construction | 4 core; colour-coded insulated conductors with fire-resistant insulation system |
| Screening | Overall foil screen |
| Drain wire | Drain wire included |
| Outer-jacket options | Fire-resistant LSZH |
| Cable form | Round |
| Standard colours | Red / Orange / White |
| Package length | 305 m standard package |
| Typical applications | Voice-alarm, emergency communication and public-address evacuation circuits |
AWG / NOMINAL AREA / SERIES AVAILABILITY
| AWG | NOMINAL AREA | SERIES AVAILABILITY |
| 14 AWG | 2.08 mm² | Fire-resistant LSZH • Red / Orange / White • 305 m |
| 16 AWG | 1.31 mm² | Fire-resistant LSZH • Red / Orange / White • 305 m |
| 18 AWG | 0.823 mm² | Fire-resistant LSZH • Red / Orange / White • 305 m |
Additional information
| Jacket Type | LSZH |
|---|---|
| Colour | Orange, Red, White |
| AWG | 14 awg, 16 awg, 18 awg |
| Brand | TMT Global |
| Length | 305 m |
Ordering Information
| Item Name | Item Code / SKU | Series | AWG / mm² | Jacket | Colour | Pack | QR Code |
|---|---|---|---|---|---|---|---|
| 4 Core Enhanced Fire-Resistant Voice Alarm Cable | 04C-S-VE | 14 awg | LSZH | Red | 305 m |  | |
| 4 Core Enhanced Fire-Resistant Voice Alarm Cable | 04C-S-VE | 14 awg | LSZH | Orange | 305 m | | |
| 4 Core Enhanced Fire-Resistant Voice Alarm Cable | 04C-S-VE | 14 awg | LSZH | White | 305 m | | |
| 4 Core Enhanced Fire-Resistant Voice Alarm Cable | 04C-S-VE | 16 awg | LSZH | Red | 305 m | | |
| 4 Core Enhanced Fire-Resistant Voice Alarm Cable | 04C-S-VE | 16 awg | LSZH | Orange | 305 m | | |
| 4 Core Enhanced Fire-Resistant Voice Alarm Cable | 04C-S-VE | 16 awg | LSZH | White | 305 m | | |
| 4 Core Enhanced Fire-Resistant Voice Alarm Cable | 04C-S-VE | 18 awg | LSZH | Red | 305 m | | |
| 4 Core Enhanced Fire-Resistant Voice Alarm Cable | 04C-S-VE | 18 awg | LSZH | Orange | 305 m | | |
| 4 Core Enhanced Fire-Resistant Voice Alarm Cable | 04C-S-VE | 18 awg | LSZH | White | 305 m | |
