3 Core Unshielded PA / Paging Cable
KEY FEATURES
- Three colour-coded bare-copper conductors
- Unshielded round cable construction
- PVC, LSZH and PE Outdoor variants
- Designed for paging and PA control circuits
- Exact searchable ordering rows
Description
TMT Global 3 Core Unshielded PA / Paging Cable Series
TMT Global 3 Core Unshielded PA / Paging Cable is a multi-conductor family for paging stations, common/return circuits, control contacts and commercial-audio wiring that does not require an overall screen. Core count defines the product page; AWG and jacket remain ordering-row attributes.
KEY FEATURES
- Three colour-coded bare-copper conductors
- Unshielded round cable construction
- PVC, LSZH and PE Outdoor variants
- Designed for paging and PA control circuits
- Exact searchable ordering rows
TYPICAL APPLICATIONS
- Paging call stations
- PA control and common circuits
- Intercom signalling
- Commercial-audio contact wiring
- Building communication systems
Technical Specification
| PARAMETER | SPECIFICATION |
| Product type | PA / paging / commercial-audio bulk cable |
| Geometry / configuration | 3 core |
| Conductor material | Bare copper |
| Conductor construction | Stranded copper conductors |
| Available conductor sizes | 14 AWG / 16 AWG / 18 AWG / 20 AWG |
| Conductor identification | Colour-coded insulated conductors |
| Core / pair construction | 3 colour-coded insulated conductors |
| Screening | Unshielded |
| Drain wire | Not applicable |
| Outer-jacket options | PVC / LSZH / PE Outdoor |
| Cable form | Round |
| Standard colours | Grey (PVC/LSZH) / Black (PE Outdoor) |
| Package length | 305 m standard package |
| Typical applications | Paging stations, PA control circuits, intercom signalling and building communication |
AWG / NOMINAL AREA / SERIES AVAILABILITY
| AWG | NOMINAL AREA | SERIES AVAILABILITY |
| 14 AWG | 2.08 mm² | PVC / LSZH / PE Outdoor • 305 m |
| 16 AWG | 1.31 mm² | PVC / LSZH / PE Outdoor • 305 m |
| 18 AWG | 0.823 mm² | PVC / LSZH / PE Outdoor • 305 m |
| 20 AWG | 0.519 mm² | PVC / LSZH / PE Outdoor • 305 m |
Additional information
| Brand | TMT Global |
|---|---|
| Jacket Type | LSZH, PE Outdoor, PVC |
| AWG | 14 awg, 16 awg, 18 awg, 20 awg |
| Length | 305 m |
| Colour | Black, Grey |
Ordering Information
| Item Name | Item Code / SKU | Series | AWG / mm² | Jacket | Colour | Pack | QR Code |
|---|---|---|---|---|---|---|---|
| 3 Core Unshielded PA / Paging Cable | 03C-U-PA | 14 awg | PVC | Grey | 305 m |  | |
| 3 Core Unshielded PA / Paging Cable | 03C-U-PA | 14 awg | LSZH | Grey | 305 m | | |
| 3 Core Unshielded PA / Paging Cable | 03C-U-PA | 14 awg | PE Outdoor | Black | 305 m | | |
| 3 Core Unshielded PA / Paging Cable | 03C-U-PA | 16 awg | PVC | Grey | 305 m | | |
| 3 Core Unshielded PA / Paging Cable | 03C-U-PA | 16 awg | LSZH | Grey | 305 m | | |
| 3 Core Unshielded PA / Paging Cable | 03C-U-PA | 16 awg | PE Outdoor | Black | 305 m | | |
| 3 Core Unshielded PA / Paging Cable | 03C-U-PA | 18 awg | PVC | Grey | 305 m | | |
| 3 Core Unshielded PA / Paging Cable | 03C-U-PA | 18 awg | LSZH | Grey | 305 m | | |
| 3 Core Unshielded PA / Paging Cable | 03C-U-PA | 18 awg | PE Outdoor | Black | 305 m | | |
| 3 Core Unshielded PA / Paging Cable | 03C-U-PA | 20 awg | PVC | Grey | 305 m | | |
| 3 Core Unshielded PA / Paging Cable | 03C-U-PA | 20 awg | LSZH | Grey | 305 m | | |
| 3 Core Unshielded PA / Paging Cable | 03C-U-PA | 20 awg | PE Outdoor | Black | 305 m | |
