4 Pair Foil-Shielded PA / Intercom Cable
KEY FEATURES
- Four twisted pairs / eight conductors
- Overall foil screen and drain wire
- Multi-channel PA and intercom capability
- PVC, LSZH and PE Outdoor jackets
- Exact item-code rows under one family page
Description
TMT Global 4 Pair Foil-Shielded PA / Intercom Cable Series
TMT Global 4 Pair Foil-Shielded PA / Intercom Cable provides four twisted pairs within one screened jacket for multi-channel paging, intercom and commercial-audio control applications. Pair geometry is maintained as a separate physical family from generic eight-core cable
KEY FEATURES
- Four twisted pairs / eight conductors
- Overall foil screen and drain wire
- Multi-channel PA and intercom capability
- PVC, LSZH and PE Outdoor jackets
- Exact item-code rows under one family page
TYPICAL APPLICATIONS
- PA and intercom backbone wiring
- Multiple paging channels
- Call-station and zone-control links
- Commercial-audio rack interconnection
- Multi-circuit building communication
Technical Specification
| PARAMETER | SPECIFICATION |
| Product type | Screened PA / intercom multi-pair cable |
| Geometry / configuration | 4 twisted pairs / 8 cores |
| Conductor material | Bare copper |
| Conductor construction | Stranded copper conductors |
| Available conductor sizes | 18 AWG / 20 AWG / 22 AWG / 24 AWG |
| Conductor identification | Colour-coded insulated conductors |
| Core / pair construction | 4 twisted pairs with colour-coded insulated conductors |
| Screening | Overall foil screen |
| Drain wire | Drain wire included |
| Outer-jacket options | PVC / LSZH / PE Outdoor |
| Cable form | Round |
| Standard colours | Grey (PVC/LSZH) / Black (PE Outdoor) |
| Package length | 305 m standard package |
| Typical applications | Multi-channel PA, intercom, call-station and control backbone circuits |
AWG / NOMINAL AREA / SERIES AVAILABILITY
| AWG | NOMINAL AREA | SERIES AVAILABILITY |
| 18 AWG | 0.823 mm² | PVC / LSZH / PE Outdoor • 305 m |
| 20 AWG | 0.519 mm² | PVC / LSZH / PE Outdoor • 305 m |
| 22 AWG | 0.326 mm² | PVC / LSZH / PE Outdoor • 305 m |
| 24 AWG | 0.205 mm² | PVC / LSZH / PE Outdoor • 305 m |
Additional information
| Brand | TMT Global |
|---|---|
| AWG | 18 awg, 20 awg, 22 awg, 24 awg |
| Colour | Black, Grey |
| Jacket Type | LSZH, PE Outdoor, PVC |
| Length | 305 m |
Ordering Information
| Item Name | Item Code / SKU | Series | AWG / mm² | Jacket | Colour | Pack | QR Code |
|---|---|---|---|---|---|---|---|
| 4 Pair Foil-Shielded PA / Intercom Cable | 04P-S-PI | 18 awg | PVC | Grey | 305 m |  | |
| 4 Pair Foil-Shielded PA / Intercom Cable | 04P-S-PI | 18 awg | LSZH | Grey | 305 m | | |
| 4 Pair Foil-Shielded PA / Intercom Cable | 04P-S-PI | 18 awg | PE Outdoor | Black | 305 m | | |
| 4 Pair Foil-Shielded PA / Intercom Cable | 04P-S-PI | 20 awg | PVC | Grey | 305 m | | |
| 4 Pair Foil-Shielded PA / Intercom Cable | 04P-S-PI | 20 awg | LSZH | Grey | 305 m | | |
| 4 Pair Foil-Shielded PA / Intercom Cable | 04P-S-PI | 20 awg | PE Outdoor | Black | 305 m | | |
| 4 Pair Foil-Shielded PA / Intercom Cable | 04P-S-PI | 22 awg | PVC | Grey | 305 m | | |
| 4 Pair Foil-Shielded PA / Intercom Cable | 04P-S-PI | 22 awg | LSZH | Grey | 305 m | | |
| 4 Pair Foil-Shielded PA / Intercom Cable | 04P-S-PI | 22 awg | PE Outdoor | Black | 305 m | | |
| 4 Pair Foil-Shielded PA / Intercom Cable | 04P-S-PI | 24 awg | PVC | Grey | 305 m | | |
| 4 Pair Foil-Shielded PA / Intercom Cable | 04P-S-PI | 24 awg | LSZH | Grey | 305 m | | |
| 4 Pair Foil-Shielded PA / Intercom Cable | 04P-S-PI | 24 awg | PE Outdoor | Black | 305 m | |
