2 Core Foil-Shielded Installation Microphone Cable
KEY FEATURES
- Fixed-installation balanced pair geometry
- Overall aluminium/polyester foil screen with drain wire
- 18, 20 and 22 AWG Series options
- PVC, LSZH and PE Outdoor jacket options
- 305 m standard bulk-cable package
Description
TMT Global 2 Core Foil-Shielded Installation Microphone Cable Series
TMT Global 2 Core Foil-Shielded Installation Microphone Cable is designed as a fixed-installation balanced microphone and low-level audio family for conduits, trays, wall plates, floor boxes, racks and central equipment rooms. The foil screen and drain wire support efficient termination, while AWG and jacket remain Series ordering attributes.
KEY FEATURES
- Fixed-installation balanced pair geometry
- Overall aluminium/polyester foil screen with drain wire
- 18, 20 and 22 AWG Series options
- PVC, LSZH and PE Outdoor jacket options
- 305 m standard bulk-cable package
TYPICAL APPLICATIONS
- Installed microphone wall plates and floor boxes
- Conference, education and hospitality AV
- Theatre, venue and house-of-worship infrastructure
- Rack rooms, patch bays and audio interfaces
- Protected outdoor microphone circuits where approved
Technical Specification
| PARAMETER | SPECIFICATION |
| Product type | Fixed-installation balanced microphone and low-level analogue audio cable |
| Geometry / configuration | 1 balanced pair / 2 core |
| Conductor material | Bare copper |
| Conductor construction | Stranded copper |
| Available conductor sizes | 18 AWG / 20 AWG / 22 AWG |
| Signal construction | One balanced pair / two insulated signal conductors |
| Core insulation | PE / PVC / halogen-free compound, construction dependent |
| Screening | Overall aluminium/polyester foil screen + drain wire |
| Outer-jacket options | PVC / LSZH / PE Outdoor |
| Cable form | Round |
| Standard colour | Black |
| Primary application | Fixed-installation microphone, wall-plate and low-level audio circuits |
| Construction use | Fixed-installation microphone bulk cable |
| Standard package | 305 m |
| Alternate package lengths | 100 m and project lengths by Series row |
AWG / NOMINAL AREA / SERIES AVAILABILITY
| AWG | NOMINAL AREA | SERIES AVAILABILITY |
| 18 AWG | 0.823 mm² | PVC / LSZH / PE Outdoor • 305 m |
| 20 AWG | 0.519 mm² | PVC / LSZH / PE Outdoor • 305 m |
| 22 AWG | 0.326 mm² | PVC / LSZH / PE Outdoor • 305 m |
Additional information
| AWG | 18 awg, 20 awg, 22 awg |
|---|---|
| Jacket Type | LSZH, PE Outdoor, PVC |
| Length | 305 m |
| Colour | Black |
| Brand | TMT Global |
Ordering Information
| Item Name | Item Code / SKU | Series | AWG / mm² | Jacket | Colour | Pack | QR Code |
|---|---|---|---|---|---|---|---|
| 2 Core Foil-Shielded Installation Microphone Cable | 02S-MI | 18 awg | PVC | Black | 305 m |  | |
| 2 Core Foil-Shielded Installation Microphone Cable | 02S-MI | 18 awg | LSZH | Black | 305 m | | |
| 2 Core Foil-Shielded Installation Microphone Cable | 02S-MI | 18 awg | PE Outdoor | Black | 305 m | | |
| 2 Core Foil-Shielded Installation Microphone Cable | 02S-MI | 20 awg | PVC | Black | 305 m | | |
| 2 Core Foil-Shielded Installation Microphone Cable | 02S-MI | 20 awg | LSZH | Black | 305 m | | |
| 2 Core Foil-Shielded Installation Microphone Cable | 02S-MI | 20 awg | PE Outdoor | Black | 305 m | | |
| 2 Core Foil-Shielded Installation Microphone Cable | 02S-MI | 22 awg | PVC | Black | 305 m | | |
| 2 Core Foil-Shielded Installation Microphone Cable | 02S-MI | 22 awg | LSZH | Black | 305 m | | |
| 2 Core Foil-Shielded Installation Microphone Cable | 02S-MI | 22 awg | PE Outdoor | Black | 305 m | |
