4 Core Round Foil Shielded Commercial Speaker Cable
KEY FEATURES
- 4 flexible colour-identified conductors
- Overall aluminium/polyester foil screen and drain wire
- 14, 16, 18 and 20 AWG Series options
- PVC, LSZH and outdoor PE jacket choices
- Screened round construction for project applications
- Exact searchable item code for every released combination
Description
TMT Global 4 Core Round Foil Shielded Commercial Speaker Cable Series
TMT Global 4 Core Round Foil Shielded Commercial Speaker Cable is a screened multi-channel family for two speaker circuits, selected bi-wire layouts and commercial sound systems in higher-EMI environments. The four-core foil-screened construction defines the product page; AWG and jacket define exact Series SKUs.
KEY FEATURES
- 4 flexible colour-identified conductors
- Overall aluminium/polyester foil screen and drain wire
- 14, 16, 18 and 20 AWG Series options
- PVC, LSZH and outdoor PE jacket choices
- Screened round construction for project applications
- Exact searchable item code for every released combination
TYPICAL APPLICATIONS
- Two-channel commercial audio routes
- Screened bi-wire and selected speaker circuits
- Intercom, paging and distributed sound projects
- Industrial and infrastructure audio systems
- Hospitality, transport and public-building AV
Technical Specification
| PARAMETER | SPECIFICATION |
| Product type | Foil-shielded multi-channel commercial speaker cable |
| Core configuration | 4 flexible colour-identified conductors |
| Conductor material | Bare copper |
| Conductor construction | Flexible high-strand speaker conductor |
| Available conductor sizes | 14 / 16 / 18 / 20 AWG |
| Core identification | Four individually colour-identified insulated conductors |
| Screening | Overall aluminium/polyester foil screen |
| Drain wire | Tinned-copper drain wire for screen continuity |
| Outer-jacket options | PVC / LSZH / PE Outdoor |
| Cable form | Round |
| Standard colours | Grey indoor / Black outdoor |
| Typical use | Two-channel commercial audio, paging and screened speaker circuits |
| Installation environment | Indoor; outdoor routes with PE Outdoor Series variants |
| Package length | 305 m standard TMT package |
AWG / NOMINAL AREA MATRIX
| AWG | NOMINAL AREA | SERIES AVAILABILITY |
| 14 AWG | 2.08 mm² | PVC / LSZH / PE Outdoor • Foil + drain • 305 m |
| 16 AWG | 1.31 mm² | PVC / LSZH / PE Outdoor • Foil + drain • 305 m |
| 18 AWG | 0.823 mm² | PVC / LSZH / PE Outdoor • Foil + drain • 305 m |
| 20 AWG | 0.518 mm² | PVC / LSZH / PE Outdoor • Foil + drain • 305 m |
Additional information
| AWG | 14 awg, 16 awg, 18 awg, 20 awg |
|---|---|
| Brand | TMT Global |
| Colour | Black, Grey |
| Jacket Type | LSZH, PE Outdoor, PVC |
| Length | 305 m |
Ordering Information
| Item Name | Item Code / SKU | Series | AWG / mm² | Jacket | Colour | Pack | QR Code |
|---|---|---|---|---|---|---|---|
| 4 Core Round Foil Shielded Commercial Speaker Cable | 04SR-SR | 14 awg | PVC | Grey | 305 m |  | |
| 4 Core Round Foil Shielded Commercial Speaker Cable | 04SR-SR | 14 awg | LSZH | Grey | 305 m | | |
| 4 Core Round Foil Shielded Commercial Speaker Cable | 04SR-SR | 14 awg | PE Outdoor | Black | 305 m | | |
| 4 Core Round Foil Shielded Commercial Speaker Cable | 04SR-SR | 16 awg | PVC | Grey | 305 m | | |
| 4 Core Round Foil Shielded Commercial Speaker Cable | 04SR-SR | 16 awg | LSZH | Grey | 305 m | | |
| 4 Core Round Foil Shielded Commercial Speaker Cable | 04SR-SR | 16 awg | PE Outdoor | Black | 305 m | | |
| 4 Core Round Foil Shielded Commercial Speaker Cable | 04SR-SR | 18 awg | PVC | Grey | 305 m | | |
| 4 Core Round Foil Shielded Commercial Speaker Cable | 04SR-SR | 18 awg | LSZH | Grey | 305 m | | |
| 4 Core Round Foil Shielded Commercial Speaker Cable | 04SR-SR | 18 awg | PE Outdoor | Black | 305 m | | |
| 4 Core Round Foil Shielded Commercial Speaker Cable | 04SR-SR | 20 awg | PVC | Grey | 305 m | | |
| 4 Core Round Foil Shielded Commercial Speaker Cable | 04SR-SR | 20 awg | LSZH | Grey | 305 m | | |
| 4 Core Round Foil Shielded Commercial Speaker Cable | 04SR-SR | 20 awg | PE Outdoor | Black | 305 m | |
