12-Core 1U Fixed Rack ODF — SC Unloaded

TMT Global 12-Core 1U Fixed Rack ODF — SC Unloaded Series

The TMT Global 12-Core 1U Fixed Rack ODF — SC Unloaded is a controlled fibre distribution platform for organised termination, splicing and patching. The approved product specification defines the declared capacity, mounting format, access construction, optical interface, loading arrangement, splice capacity and enclosure format. It is intended for professional fibre-optic systems in Europe and the Middle East, with supplier/OEM production required to match the approved TMT specification.

KEY FEATURES

• Fixed rack-tray construction
• Front adapter access and protected rear cable entry
• Removable splice-tray support
• Earthing provision for metal chassis

APPLICATIONS

• Enterprise fibre backbones
• Data-centre cross-connects
• Campus and building distribution
• Telecom equipment rooms

OEM / PUBLICATION POSITIONING

Publication status: controlled datasheet content; final project/certification claims remain subject to supplier evidence and TMT release approval.

STANDARDS / TEST BASIS

• Rack mechanics — IEC 60297-3-100 where applicable
• Connector interface — IEC 61754 series where adapters/interfaces are fitted
• Passive component tests — IEC 61300 series where applicable
• System application — ISO/IEC 11801 and EN 50173 context
• Materials — RoHS and REACH supplier declarations required
• Fire note — Cable fire classes apply to installed cables, not the empty ODF chassis
• Evidence — Supplier/OEM conformity and test evidence retained before release

QUALITY / ACCEPTANCE

• Dimensional inspection, fit/function checks, material declarations and applicable interface/component test evidence
• Any material, construction or loading change affecting fit, function, optical performance, durability or compliance requires prior TMT approval
• Acceptance of a purchase order confirms production will match this controlled specification and approved golden sample/BOM

TECHNICAL SPECIFICATION
