Cat6a 23awg 4 twisted pair SF-UTP Network Cable 305m

TMT Global  cat6a 23awg 4 twisted pair SF-UTP Network Cable 305m

TMT global Cat6a 23awg 4 twisted pair SF-UTP Network Cable 305m is manufactured, tested, and compliant with ANSI/TIA-568.2-D, CENELEC EN 50288-5, and IEC 61156-5 (ISO/IEC 11801 Class E), including Amendment A1:2010 requirements for patch cord assemblies, and provides high performance levels for structured cabling systems.

TMT Global Technology LTD aims to provide the best quality products in Structured Cabling Systems, Copper and Fiber Optics Range, Access Control Systems, Gate Automation, Lighting Control Systems, PIR Motion Sensors, UHF Long Range Readers, Automatic Parking Solutions, SMATV Systems, Audio Video Intercom Systems, Audio Visual Systems, and Public Address Systems. Industrial and Building Automation Cables and Accessories lead to customer satisfaction and reliability. All TMT Global products meet or exceed rigorous industry and regulatory standards for quality, reliability, and efficiency. From design and fabrication to finished product assembly, each phase in the manufacturing process is meticulously executed.

PHYSICAL AND MECHANICAL PROPERTIES

Basic Conductor: 23AWG Bare Copper
Insulation: HDPE
Number of insulated conductors: 8 twisted in 4 pairs
Color Code of Pairs: Blue x White/Blue, Orange x White/Orange, Green x White/Green, Brown x White/Brown
Outer Jacket: PVC
Standard Jacket Color: Black /Grey/Blue/Orange/ Green/White/Aqua/ Yellows/Violet/Red
Standard Surface Marking: Includes TMT Global P/N, cable description, Meter mark and Model Number
Pulling force: 100 N MAX.
Short Term Bend Radius: 6xOD (Mm)
Storage Temperature: -20 To +80C
Temperature operating range: -20 to +60C
Installation temperature range: 0 to +50C
Flame Test: IEC 60332-1

ELECTRICAL SPECIFICATIONS

Characteristic Impedance: 100―6 Ohm @ 1-100 MHz
DC Resistance: 93 Ohm/Km max.
Resistance unbalance: 2% max.
Mutual Capacitance: 5.6 nF/100m Max. @ 1 KHz
Cap. Unbalance (wire to ground): 1500 pF/Km max. @ 1 KHz.
Voltage rating: 72 Vdc max.
Dielectric strength: 1500 Volts/1 minute min rms
Velocity of Propagation (NVP): 67-69%
Insulation Resistance: 5000 MOhm•m min. @ 500 Vdc
Coupling attenuation: IEC 61156-5 TYPE III
