Cat6 Green Cable 24awg 4 twisted pair F-UTP 305m

(1 customer review)

$280.00

Standards: ANSI/TIA/568.2-D CENELEC EN 50288-5IEC 61156-5 (ISO/IEC-11801 Class -E)


General Specification:

Conductor: TMT Copper
Conductor Size: 24AWG
No. Of Pairs: 4 twisted pairs
Overall Coverage: N/L
Outer Jacket: PVC
Jacket Color: Black/Grey/Violet/Orange
Packing: 305m
Item Code: 6X246MPB

tmt global Color

tmt global Aqua Color

,

tmt global Black Color

,

tmt global Blue Color

,

tmt global Gray Color

,

tmt global Green Color

,

tmt global Orange Color

,

tmt global Red Color

,

tmt global Violet Color

,

tmt global white Color

,

tmt global Yellow Color

Brand

TMT Global

Description

TMT Global  Cat6 Network Cable 23awg 4 twisted pair F-UTP Outdoor 305m

TMT Global Technology LTD aims to provide the best quality products, including structured cabling systems, copper and fiber optics range, access control systems, gate automation, lighting control systems, PIR motion sensors, UHF long-range readers, automatic parking solutions, SMATV systems, audio video intercom systems, audio visual systems, and public address systems. Industrial and building automation cables and accessories lead to customer satisfaction and reliability. All TMT Global products meet or exceed rigorous industry and regulatory standards for quality, reliability, and efficiency. From design and fabrication to finished product assembly, each phase in the manufacturing process is rigorously monitored and measured to ensure the highest quality, durability, and operating excellence.Cat6 Green Cable 24awg 4 twisted pair F-UTP 305m

PHYSICAL AND MECHANICAL PROPERTIES
Basic ConductorTMT Copper
Conductor Size23AWG
InsulationHDPE
Number Of Insulated Conductors8, Twisted In 4 Pairs
Color Code Of PairsBlue X White/Blue, Orange X White/Orange, Green X White/Green, Brown X White/Brown
Outer JacketLSZH
Standard Jacket ColorGray/Blue/Black
Standard Surface MarkingIncludes  TMT GLOBAL  P/N, Cable Description, Meter Mark And Batch Number
Pulling Force100 N MAX
Short Term Bend Radius6xOD (Mm)
Storage Temperature-20 To +80C
Temperature Operating Range-20 To +60C
Installation Temperature Range0 To +50C
Flame TestIEC 60332-1
ELECTRICAL SPECIFICATIONS
Characteristic Impedance100―6 Ohm @ 1-100 MHzDielectric Strength1500 Volts/1 Minute Min Rms
DC Resistance93 Ohm/Km Max.Velocity Of Propagation (NVP)67-69%
Resistance Unbalance2% Max.Insulation Resistance5000 Mega Ohm•Km Min. @ 500 Vdc
Mutual Capacitance5.6 NF/100m  Max.   @ 1 KHzCoupling AttenuationIEC 61156-5 TYPE III
Cap. Unbalance (Wire To Ground)1500 PF/Km Max. @ 1 KHz.
Voltage Rating72 Vdc Max.



Reviews (1)

1 review for Cat6 Green Cable 24awg 4 twisted pair F-UTP 305m

  1. khan

    The tmt global Cat 6 Network Cable 23awg LSZH 305m is a commendable choice for those seeking reliable and high-performance networking solutions. With its 23 AWG wire gauge, this cable offers improved signal integrity and reduced attenuation, making it suitable for both residential and commercial applications. The low smoke zero halogen (LSZH) material enhances safety by minimizing harmful emissions in the event of a fire. Additionally, the 305-meter length provides ample length for extensive installations without the need for additional connectors. Overall, this product delivers excellent durability and performance, ensuring a seamless internet experience for users.
